FAE BL1/EX – BL1/EX/VT Forestry Excavator Mulcher

Share:

Features

12 cm Max Cut Diameter
355 kg Weight
180-350 Bar recommended working pressure
4-7.5 t recommended base machine size
50-140 l/min recommended flow volume
Working Width: 800mm
2 Models

Forestry mulcher with Bite Limiter technology.

FAE introduces a new line of professional mulchers for excavators equipped with Bite Limiter technology.
Special steel limiter rings limit the depth of blade action, reducing the demand for power, guaranteeing speed and exceptional performance.
The BL1/EX – BL1/EX/VT (for 4-7.5 t excavators) has a 800 mm working width and can mulch logs up to 12 cm in diameter.
The piston engine (with manually controlled variable displacement) makes it easy to use this mulcher on different excavators with different oil flow rates.
The BL1/ EX-BL1/EX/VT forestry excavator mulcher has a rotor equipped with a heat-treated forged steel tooth holder, together with Type Mini BL blades.
This light, compact mulcher is easy to manoeuvre and perfect for various types of forestry work.

Standard equipment:

  • Enclosed/anti dust machine body
  • Motor enclosed in the frame
  • Bulkhead for hydraulic connections
  • Transmission with belts
  • 55/38cc variable torque hydraulic piston motor (VT)
  • 17/34cc variable manual displacement hydraulic piston motor with relief and anticavitation valve (BL1/EX)
  • Bite Limiter Rotor
  • Flow control system valve
  • Safety and anticavitation valve
  • Front hood with mechanical adjustment
  • Dedicated rear hood (deflector)

Options: Diverter valve (plug in and play), hydraulic front hood for excavator aux line, hydraulic front trap door, customised setting hydraulic motor, front fixed thumb bracked, customized attachment bracket with pins, multiple tooth options.

FAE Group is a world leader in the design and construction of professional machinery for road construction, agricultural and forestry applications.

FAE MEANS QUALITY, RELIABILITY, AND INNOVATION.

For over 25 years they have been offering cutting edge, innovative solutions in design and technology and unique due to the quality of the materials and performance. The wide range of forestry mulchers & tillers are stocked by Jas P Wilson’s.
