Krpan CV 22 K Pro Log Splitter



110 cm Log Length
Vertical Log Splitter
21 t Splitting Force
PTO Power Options

The KRPAN CV 22 K pro is a vertical firewood log splitter with 21T splitting force. With adjustable height for easier transportation and storage, and a mechanical log lifting device, this splitter can split logs with a height up to 110cm.

Technical features

DriveP.T.O. shaft
Drive Power/
Splitting Force21 t
Piston Hub970 mm
Splitting Height550/1100 mm
Splitting Speed (S2– S1)-R*(s/1000mm)(3,6-7,2)-3,6
Oil Flow73 (540) min-1
Oil Quantity in Tank40 l
Recommended Tractor Power27 kW / 37 HP
Dimensions W×L×H×(Ht)**805×1260×2850×(1850) mm
Weight457 kg
Table with extension and lifting device plateOptional
Cast-Iron PumpStandard
Winch (750kg)Optional

*S2- second gear; S1- first gear; R – reverse movement of the cylinder

** HT – transport height; transport height with winch is 2100 mm

Vitli KRPAN – Robust Build Quality

Vitli KRPAN has established itself within the Forestry and Arb industry as a leading provider of high-quality machinery. Regarded across Europe, and globally for manufacturing high-quality machinery including forestry winches, firewood machinery, forestry trailer cranes and various supporting attachments for handling and processing.

Founded in 1977, KRPAN has developed this distinguished position by developing quality machines with safety, functionality, and quality as a core ethos of their design process.
KRPAN holds numerous international patents, registered designs, and trademarks. The company continues to innovate and improve its machinery to meet the evolving needs of the forestry industry while maintaining its commitment to quality craftsmanship.
